Honeweyll STT171,STT173,STT17H,STT17F,STT17C Temperature Transmitter
1.Product Introduce：
Honeywell's STT170 series intelligent temperature transmitter provides an economical solution for temperature detection applications. Compared with the direct wiring temperature measuring point,
the STT170 series intelligent temperature transmitter is more accurate, safe and reliable, while reducing the wiring cost. The temperature signal output of this temperature transmitter is automatically linearized within the upper and lower limit intervals set by the user.
In addition, users can program high and low alarm points and make them alarm when the sensor fails. When ordering the STT170 series intelligent temperature transmitter, users can order it together with Honeywell's temperature sensor and protective sleeve to form a complete and ready-to-use temperature measurement device.
2) Products Applications & Parameter for each model:
1.Product Introduce：
Honeywell's STT170 series intelligent temperature transmitter provides an economical solution for temperature detection applications. Compared with the direct wiring temperature measuring point,
the STT170 series intelligent temperature transmitter is more accurate, safe and reliable, while reducing the wiring cost. The temperature signal output of this temperature transmitter is automatically linearized within the upper and lower limit intervals set by the user.
In addition, users can program high and low alarm points and make them alarm when the sensor fails. When ordering the STT170 series intelligent temperature transmitter, users can order it together with Honeywell's temperature sensor and protective sleeve to form a complete and ready-to-use temperature measurement device.
2) Products Applications & Parameter for each model:
STT171 Features:
● Analog 4-20mA output
● RTD or resistance value input
● Type B DIN rail or head mount
● Sensor failure signal conforms to NAMUR NE43 regulations
● Use STT17C configuration tool and PC to configure it
STT173 features:
● Analog 4-20mA output
● RTD, thermocouple, resistance value or millivolt input
● Type B DIN rail or head mount
● Sensor failure signal conforms to NAMUR NE43 regulations
● Use STT17C configuration tool and PC to configure it
● Computer isolation
STT17H features:
● HART/4-20mA output
● RTD, thermocouple, resistance value or millivolt input
● Single or dual sensor (difference or average) input
● Type B DIN rail or head mount
● Can be connected to HART multi-point connection
● Sensor failure signal conforms to NAMUR NE43 regulations
● Use STT17C configuration tool and PC computer or HART field configuration to configure it
● Computer isolation
STT17F and STT17P Features:
● FOUNDATION Fieldbus (FF) or PROFIBUS PA
● RTD, thermocouple, resistance value or millivolt input
● Single or dual sensor (difference or average) input
● Type B DIN rail or head mount
● Function block: 2 AI, 1 PID
● FISCO certification
● Basic or Link Active Scheduler
● Electrical isolation
3: Parameter table
Sensor type PT100,NI100,Resistance ΩW
Accuracy ranting（ For spans greater than1/10 of URL ±0.1%
Output signal/ Power supply DC4-20mA/8~30V
Promote/inhibit -100%~+100%URL
Explosion-approvals KEMA, FM, ATEX, IECEx, CSA, EMC
Ambient temperature： -40~85˚C
For order details,pls feel free to contact us for datasheet.
3: Parameter table
Sensor type PT100,NI100,Resistance ΩW
Accuracy ranting（ For spans greater than1/10 of URL ±0.1%
Output signal/ Power supply DC4-20mA/8~30V
Promote/inhibit -100%~+100%URL
Explosion-approvals KEMA, FM, ATEX, IECEx, CSA, EMC
Ambient temperature： -40~85˚C
For order details,pls feel free to contact us for datasheet.
