Honeywell STG700 Series smartline Pressure transmitter
STG700 and STG70L are suitable for monitoring, control and data acquisition featuring piezoresistive sensor technology
STG700 and STG70L are suitable for monitoring, control and data acquisition featuring piezoresistive sensor technology
combining pressure sensing with on chip temperature compensation capabilities providing high accuracy, stability
and performance over a wide range of application pressures and temperatures. The SmartLine family is also fully tested
and compliant with Experion® PKS providing the highest level of compatibility assurance and integration capabilities.
SmartLine easily meets the most demanding application needs for pressure measurement applications.
Best in Class Features:
• Accuracies up to 0.055% of span standard & 0.04% of span optional
• Stability up to 0.02% of URL per year for 10 years
• Automatic temperature compensation
• Rangeability up to 100:1
• Response times as fast as 100ms
• Alphanumeric display capabilities
• External zero, span, & configuration capability
• Polarity insensitive electrical connections
• Comprehensive on-board diagnostic capabilities
• Integral Dual Seal design for safety based on ANSI/NFPA 70-202 and ANSI/ISA 12.27.0
• Full compliance to SIL 2/3 requirements as a standard.
• Modular design characteristics
• Available additional with 4-year warranty
